Jupiter®
Innovative Weaving
Products for Hard Armour

The JUPITER® product line provides :

  • a high performance level = higher specific energy absorption (energy/areal density) compared to traditional materials

The JUPITER® products are supplied in rolls:
having a max width = 3.2 meters (126 inch)

JUPITER® products can also be supplied already laminated (ready to be pressed) with thermoplastic or thermoset films having weight in accordance with customer’s request.

Jupiter<sup>®</sup>
General Terms and Conditions of Sale and Delivery
Product name Product Code Areal Density*
UNI EN 12127 		Standard
Roll Length**		 Roll  Width
UNI EN 1773		 Product description
[gr/m2] [oz/yd2] meter yard cm inch
Jupiter 370 JPT370 370 10.91 100 109 160 63" greige fabric
Jupiter 370 PH JPT370PH 420 12.39 100 109 160 63" fabric laminated with phenolic film
Jupiter 370 TP JPT370TP 420 12.39 100 109 160 63" fabric laminated with thermoplastic film
Jupiter 400 JPT400 390 11.80 100 109 160 63" greige fabric
Jupiter 400 PH JPT400PH 440 13.27 100 109 160 63" fabric laminated with phenolic film
Jupiter 400 TP JPT400TP 440 13.27 100 109 160 63" fabric laminated with thermoplastic film

* Areal Density tolerance is ± 4%
** The exact roll length is specified in the box label
