Kuralon®

Concrete and Mortar Reinforcement

Kuralon® is a synthetic fiber made of Poly-Vinyl-Alcohol (PVA) polymer that has been used since many years in concrete and mortar applications.
Kuralon® increases the ductility, the resistance to cracks, the resistance to fire and the durability of concrete and mortar.

Special features:
  • High strength
  • High modulus
  • Low elongation
  • Good adhesion to cement matrix
  • Alkaline resistance
  • UV resistance
  • Light specific weight
  • Excellent resistance
    to environmental
    conditions
 Main applications:
  • Building wall/facade
  • Bridge deck slab
  • OA panel for floor
  • Wind proof panel for railways
  • Retrofit
  • Tunnel lining
  • Shotcrete for slope stabilization
  • Overlay for road pavement
  • Concrete slab on grade
Kuralon<sup>®</sup>
General Terms and Conditions of Sale and Delivery
KURALON™ has unique properties compared with other
fiber material such as Steel, AR-Glass, Polypropylene.


Fiber Properties KURALON™ Steel AR-Glass Poltpropylene
Texile Strength MPa 880-1600 1200 2200 400
Specific Tensile Strength MPa 680-1200 150 800 440
Elongation at Break % 6 3-4 0,5 25
Young's Modulus GPa 25-41 200 80 5
Density g/cm3 1.30 7.80 2.70 0.91


Product Range
Item Diameter Cut Length Tensile
Strength		 Elongation at
Break		 Modulus Bag Size Bundled
µm mm GPa % GPa kg/bag
RMS702/6mm 26 6 1.6 6.0 39 15 •
RSC15/8mm* 40 8 1.4 6.5 36 18
REC15/8mm 40 8 1.6 6.5 41 18
REC15/12mm 40 12 1.6 6.5 41 18
RECS15/8mm 40 8 1.6 6.5 41 18 •
RECS15/12mm 40 12 1.6 6.5 41 15 •
RECS100/12mm 100 12 1.2 12.5 28 10 •
RF400/6mm 200 6 1.0 9.0 27 15
RF400/12mm* 200 12 1.0 9.0 27 10
RFS400/18mm* 200 18 1.0 9.0 27 15 •
RFS1000/15mm* 310 15 1.0 6.0 29 8
RF4000/30mm* 660 30 0.9 9.0 23 10

*CE mark certified EN14889-2:2006
